11303 | Skimmer with face plate and extended throat - for concrete pools

EAN: 8420382011418

Trade Customers log in to see price and stock information for the product.og in to see price and stock information for the product.

Technical description

• All of the components that are exposed in this range of skimmers come with a UV treatment. Made of ABS, they come with a weir flap and a flow regulator plug. Bottom suction nozzle connection: 11/2” inner thread.
• Simultaneous connection to the main drain: 2” inner thread. Overflow connection: Ø 32 mm. Round cover with spring clip fastening system.
• The height of the cover can be adjusted and turned through an extended throat, so that it sits perfectly flush with the coping stone.
• Leaf trap secured to base by means of a bayonet mount. In-built weir flap housing. Recommended flow rate: 5 m3/h.
• It is recommended that one skimmer be installed for every 25 m2 of water surface area.

Complies with Standards
EN 16582-1
EN 16713-2
